Basic configuration | |
Drive type | 6*6 |
Engine | CumminsISDe300 40 |
Gearbox | Manual Six-speed Gearbox |
Transfer box | With high and low gears |
Driver Cab | Protective Longhead Double Row Cab |
Vehicle Frame | 860×232mm |
Vehicle Axle | 5T/5T/5T |
Tire | 365/80R20 |
The car comes with a 360° reversing image, tire inflation and deflation system, under-chassis protection, intercom, police lights, ABS, and differential lock. The body is made of 4mm thick bulletproof steel plate, and the front shield is made of 40mm thick bulletproof glass.
Detailed parameter | |
Overall Dimension | 6750*2460*2480mm |
Installation Dimension | 2990*2460*1550mm |
Wheelbase | 3600+1200mm |
Wheel track | 2500mm |
GVW | 15000kg |
Curb Weight | 10740kg |
Maximum Power | 221kw |
Engine Displacement | 6.7L |
Maximum speed | 120km/h |
Engine Torque | 1100N.m |
Maximum Climbing Grade | 60% |
Approach Angle/departure Angle | 37°/43° |
Tank volume | 90+68L |
Minimum ground clearance | 340mm |
Crossing height | 550mm |
Wading Depth | 1200mm |
highest altitude | 5000m |
Frame Rear End Upper Plane Off the Ground | 1170mm |
Note: This configuration is for reference only, please refer to the actual car.
For 50% of our shipment, the vehicle will be transported by sea, to all main continents such as Africa, South America, Middle East, Oceania and Southeast Asia, either by container or RoRo/Bulk shipment. For inland neighborhood countries of China, such as Russia, Mongolia, Kazakhstan, Myanmar, Vietnam etc. , we can transport vehicles by land.
For light spare parts in urgent need. We can send it by international courier service, such as DHL, TNT, UPS, or Fedex.
On T/T term, 50% down payment is required in advance,and the 50% balance shall be settled before shipment or when products are out of the factory. T/T payment can be negotiated.
Our professional team will provide you with one-stop customs clearance service. We can provide EXW, FOB, FCA payment terms according to customers’ need.
