Basic configuration | |
Drive type | 6*6 |
Engine | B190 33 |
Gearbox | Manual Six-speed gearbox |
Transfer box | Mechanical, two speed gears |
Driver Cab | Dongfeng Double Glass Pointed Head Single Row |
Vehicle Axle | 3.5T/3.5T/3.5T |
Tire | 12R20(6+1) |
Cargo box | Large space with two air condition inside |
Vehicle Suspension | Steel Plate Spring 9/12 |
Other | With towing hook, electrical connector, air brake connector, cold start, winch |
Optional items | Reversing camera, secondary fuel tank, anti-aircraft lights |
Remarks: 260L is equipped with brake cooling water tank and 44100N front mechanical winch.The compartment is of corrugated construction with outward opening container doors on the right side and rear, with outline lights on all sides and one external power connection. The compartment is equipped with 2 exhaust fans and 2 sets of 1.5p air-conditioners.
Note: When using the air-conditioner, the vehicle needs to be kept in a horizontal position.
Detailed parameter | |
Overall Dimension | 7680*2355*2480mm |
Container Dimensions | 5100×2200×2100mm |
Wheelbase | 3600+1250mm |
Tread | 1960mm |
GVW | 10800kg |
Curb Weight | 7180kg |
Displacement | 5880ml |
Maximum speed | ≥90km/h |
Maximum Climbing Grade | |
Approach Angle/departure Angle | 31°/14° |
Tank volume | 300L |
Minimum ground clearance | 320mm |
Obstacle Crossing height | 480mm |
Wading depth | 1225mm |
Frame Rear End Upper Plane Off the Ground | 1130mm |
Note: This configuration is for reference only, please refer to the actual car.
For 50% of our shipment, the vehicle will be transported by sea, to all main continents such as Africa, South America, Middle East, Oceania and Southeast Asia, either by container or RoRo/Bulk shipment. For inland neighborhood countries of China, such as Russia, Mongolia, Kazakhstan, Myanmar, Vietnam etc. , we can transport vehicles by land.
For light spare parts in urgent need. We can send it by international courier service, such as DHL, TNT, UPS, or Fedex.
On T/T term, 50% down payment is required in advance,and the 50% balance shall be settled before shipment or when products are out of the factory. T/T payment can be negotiated.
Our professional team will provide you with one-stop customs clearance service. We can provide EXW, FOB, FCA payment terms according to customers’ need.
