Basic configuration |
Drive type | 4*2 |
Engine | Cummins ISDe210 30 |
Transmission | Shou chi Manual 6-speed |
Driver Cab | Dongfeng Longhead Single row |
Vehicle Axle |
Dont Alxe 5T/Rear Alxe 10T
|
Tire | 10.00R20（6+1) |
Detailed parameter |
Overall Dimension | 7260×2500×2980mm |
Cargobox Dimensions | 4800×2300×900mm |
Wheelbase | 3950mm |
Wheel track | 1960/1860mm |
GVW | 18000kg |
Curb Weight | 5850kg |
Maximum Power | 155kw |
Engine Displacement | 6.7L |
Maximum speed | ≥85km/h |
Fording depth | 480mm |
Approach Angle/departure Angle | 22°/21° |
Tank volume | 160L |
Minimum ground clearance | 280mm |
Note: This configuration is for reference only, please refer to the actual car.
