Basic configuration | |
Engine | Cummins B170 33 |
Drive type | 6*6 |
Gearbox | Mechanical Manual Five-speed Gearbox |
Transfer box | Time-sharing Six-wheel drive With High and Low Gears |
Driver Cab | Dongfeng Flathead One-and-a-half Row Cab |
Vehicle Frame | 860*232mm |
Vehicle Axle | 2.6T/2.6T/2.6T |
Tire | 305/80R18 |
Vehicle Suspension | Steel Plate Spring 10/13 |
Electric Circuit | 24V Electric Circuit System |
Others | Tarpaulin poles, Accompanying Tools, 200LBrake Cooling Tank, Tool box |
Optional | Air Conditioning |
Detailed parameter | |
Overall Vehicle Dimension | 6720*2480*3610mm |
Cargo Box Dimension | 3600*2300*800mm |
Wheelbase | 3130+1065mm |
Wheel Track | 1774mm |
GVW | 7800kg |
Curb Weight | 5250kg |
Number of Passenfers | 3 |
Engine Displacement | 5900ml |
Maximum Power | 125kw |
Maximum speed | 87km/h |
Torque | 560N.m/1300rpm |
Approach Angle/departure Angle | 26°/43° |
Oil Tank volume | 160L |
Minimum ground clearance | 285mm |
Wading depth | 1100mm |
Note: This configuration is for reference only, please refer to the actual car.
For 50% of our shipment, the vehicle will be transported by sea, to all main continents such as Africa, South America, Middle East, Oceania and Southeast Asia, either by container or RoRo/Bulk shipment. For inland neighborhood countries of China, such as Russia, Mongolia, Kazakhstan, Myanmar, Vietnam etc. , we can transport vehicles by land.
For light spare parts in urgent need. We can send it by international courier service, such as DHL, TNT, UPS, or Fedex.
On T/T term, 50% down payment is required in advance,and the 50% balance shall be settled before shipment or when products are out of the factory. T/T payment can be negotiated.
Our professional team will provide you with one-stop customs clearance service. We can provide EXW, FOB, FCA payment terms according to customers’ need.
