2.5-ton 3-axle All-wheel Drive Off-road Transport Vehicle
6×6 Long-hood Multifunctional Mountain Truck
Dongfeng EQ240 Off-road Cargo Truck
Basic configuration |
Drive type | 6*6 |
Engine | B170 33 |
Transmission | Shou chi Manual 5-speed |
Transfer case | High and Low Gears |
Driver Cab | Dongfeng Sharp-nosed Single-row |
Vehicle Axle |
Dont Alxe 2.5T/Middle Alxe 2.5T/Rear Alxe 2.5T
|
Tire | 11R18（6+1 Pieces） |
Electric circuit | 24V circuit system |
Leaf Spring | 9/13 |
Optional | Air Conditioner,Winch,Brake Cooling Water Tank |
Detailed parameter |
Overall Dimension | 6660×2380×2880mm |
Cargobox Dimensions | 3600*2300*900mm |
Wheelbase | 3190+1100mm |
Wheel track | 1780mm |
GVW | 7800kg |
Curb Weight | 5090kg |
Loading Weight | 2500kg |
Maximum Power | 125kw |
Engine Displacement | 5.9L |
Reatd Power | 125kw |
Number of members | 3 |
Maximum speed | ≥85km/h |
Front/Rear overhang | 1200mm/1170mm |
Approach Angle/departure Angle | 37°/46° |
Tank volume | 140+70L |
Minimum ground clearance | 285mm |
Maximum Climbing Capacity | 60% |
Minimum Turning Diameter | 18.8m |
Note: This configuration is for reference only, please refer to the actual car.
