Basic configuration | |
Engine | Cummins B210 33 |
| Drive type | 4*4 |
Gearbox | Manual eight-speed gearbox |
Transfer box | Mechanical high and low gears |
Vehicle Frame | 860*232mm |
| Driver Cab | Dongfeng One and a half Row Flat Head Cab (With Sleeper) |
Axle | 7T/13T |
Tire | 12.5R20(4+1pcs) |
Vehicle Suspension | Steel Plate Spring 10/12pcs |
Detailed parameter | |
Overall Vehicle Dimension | 6290×2515×3010mm |
| Modification Dimension | ≥3515mm |
| Wheelbase | 3600mm |
Wheel Track | 2030/2150mm |
GVW | 18000kg |
| Curb Weight | 5000kg |
| Engine Displacement | 5880ml |
| Power | 155Kw |
| Maximum speed | 85km/h |
| Front/Rear Overhang | 1330/1360mm |
Approach Angle/departure Angle | 28°/36° |
Oil Tank volume | 300L |
Minimum ground clearance | 360mm |
| Obstacle Crossing height | 590mm |
| Wading depth | 1065mm |
| Upper Frame Plane Off the Ground | 1230mm |
Note: This configuration is for reference only, please refer to the actual car.













For 50% of our shipment, the vehicle will be transported by sea, to all main continents such as Africa, South America, Middle East, Oceania and Southeast Asia, either by container or RoRo/Bulk shipment. For inland neighborhood countries of China, such as Russia, Mongolia, Kazakhstan, Myanmar, Vietnam etc. , we can transport vehicles by land.
For light spare parts in urgent need. We can send it by international courier service, such as DHL, TNT, UPS, or Fedex.

On T/T term, 50% down payment is required in advance,and the 50% balance shall be settled before shipment or when products are out of the factory. T/T payment can be negotiated.

Our professional team will provide you with one-stop customs clearance service. We can provide EXW, FOB, FCA payment terms according to customers’ need.
