Basic configuration | |
Drive type | 4*4 |
Engine | Cummins ISDe6.7-330 |
Gearbox | Allison automatic |
Transfer box | High and low gear |
Driver Cab | |
Vehicle Axle | 6.5T /6.5T |
Tire | 305/80R20 (4+1 strips) |
Vehicle Frame | |
Vehicle Suspension | Independent suspension |
Maximum Speed | 110km/h |
Optional items |
Detailed parameter | |
Chassis size | 6030×2400×2400mm (the highest point is the seat back) |
Wheelbase | 3800mm |
Wheeltrack | 1950/1938mm |
Winch | 8-ton front electric |
Total mass | 13000kg |
Curb Weight | 5270kg |
Displacement | 6.7L |
Power | 243kw/2500r/min |
front overhang/rear overhang | 1000mm (including winch) / 1230mm |
Approach Angle/departure Angle | 50°/38° |
Tank volume | 180L |
Minimum ground clearance /Maximum climbing grade | 440mm / 60% |
Obstacle Crossing height | 580mm |
Wading depth | 660mm |
The upper surface of the frame is off the ground | 1140mm |
Note: This configuration is for reference only. Please refer to the actual car.
For 50% of our shipment, the vehicle will be transported by sea, to all main continents such as Africa, South America, Middle East, Oceania and Southeast Asia, either by container or RoRo/Bulk shipment. For inland neighborhood countries of China, such as Russia, Mongolia, Kazakhstan, Myanmar, Vietnam etc. , we can transport vehicles by land.
For light spare parts in urgent need. We can send it by international courier service, such as DHL, TNT, UPS, or Fedex.
On T/T term, 50% down payment is required in advance,and the 50% balance shall be settled before shipment or when products are out of the factory. T/T payment can be negotiated.
Our professional team will provide you with one-stop customs clearance service. We can provide EXW, FOB, FCA payment terms according to customers’ need.
