Basic configuration | |
Drive type | 4*4 |
Engine | Cummins ISDe200 41 |
Gearbox | Allison automatic |
Transfer box | High and low gear |
Driver Cab | |
Vehicle Axle | 2.6T / 3.4T |
Tire | 305/80R18 (4+1 strips) |
Vehicle Frame | |
Vehicle Suspension | Independent suspension |
Other | |
Optional items |
Detailed parameter | |
Chassis size | 5290×2250×1710mm (the highest point is the seat back) |
Wheelbase | 3800mm |
Wheeltrack | 1843/1878mm |
Winch | 6-ton front electric |
Total mass | 6000kg |
Curb Weight | 2750kg |
Displacement | 4.5L |
Power | 147kw/2700r/min |
front overhang/rear overhang | 740mm/ 810mm |
Approach Angle/departure Angle | 48°/46° |
Tank volume | 76+39L |
Minimum ground clearance | 480mm |
Obstacle Crossing height | |
Wading depth | 590mm |
The upper surface of the frame is off the ground | 930mm |
Note: This configuration is for reference only, please refer to the actual car.
For 50% of our shipment, the vehicle will be transported by sea, to all main continents such as Africa, South America, Middle East, Oceania and Southeast Asia, either by container or RoRo/Bulk shipment. For inland neighborhood countries of China, such as Russia, Mongolia, Kazakhstan, Myanmar, Vietnam etc. , we can transport vehicles by land.
For light spare parts in urgent need. We can send it by international courier service, such as DHL, TNT, UPS, or Fedex.
On T/T term, 50% down payment is required in advance,and the 50% balance shall be settled before shipment or when products are out of the factory. T/T payment can be negotiated.
Our professional team will provide you with one-stop customs clearance service. We can provide EXW, FOB, FCA payment terms according to customers’ need.
