Basic configuration |
|
Drive type |
4*4 |
Engine |
Cummins ISDe200 41 |
Gearbox |
Allison automatic |
Transfer box |
High and low gear |
Driver Cab |
|
Vehicle Axle |
2.6T / 3.4T |
Tire |
305/80R18 (4+1 strips) |
Vehicle Frame |
|
Vehicle Suspension |
Independent suspension |
| Other | |
| Optional items | |
Detailed parameter |
|
Chassis size |
5290×2250×1710mm (the highest point is the seat back) |
Wheelbase |
3800mm |
Wheeltrack |
1843/1878mm |
Winch |
6-ton front electric |
Total mass |
6000kg |
Curb Weight |
2750kg |
Displacement |
4.5L |
Power |
147kw/2700r/min |
front overhang/rear overhang |
740mm/ 810mm |
Approach Angle/departure Angle |
48°/46° |
Tank volume |
76+39L |
Minimum ground clearance |
480mm |
Obstacle Crossing height |
|
Wading depth |
590mm |
The upper surface of the frame is off the ground |
930mm |
Note: This configuration is for reference only, please refer to the actual car.
