Dongfeng 210 hp tipper truck can carry 10 tonnes of cargo, suitable for loading and unloading earth and stone sand in the construction site mining area.
Basic configuration | |
Drive type | 4*2 |
Engine | B210 33 |
Transmission | Manual Five Speed |
Transfer case | High and low speed |
Driver Cab | Dongfeng conventional one and half row |
Vehicle Axle | |
Tire | 10.00R20(6+1) |
Electric circuit | 24V circuit system |
Leaf Spring | 9/8+9 |
Optional | Cold and warm air-conditioning、Reversing camera、Brake cooling tanks、Right hand drive cab |
Detailed parameter | |
Chassis Overall Dimension | 8250×2430×3080mm |
Cargobox Dimensions | 6200*2300*800+400mm |
Wheelbase | 4700mm |
Wheel track | 2035/1818mm |
GVW | 15000kg |
Curb Weight | 5460kg底盘6750kg整车 |
Loading Weight | 5000kg |
Maximum Power | 155kw |
Engine Displacement | 5900ml |
Engine Power | 155kw |
Number of pasengers | |
Maximum speed | 90km/h |
Front/Rear overhang | 1340mm/2610mm底盘3020mm整车 |
Approach Angle/departure Angle | 26°/15°底盘12°整车 |
Tank volume | 300L |
Minimum ground clearance | 280mm |
Fording Depth | 510mm |
Ground clearance of rear frame | 1090mm |
Note: This configuration is for reference only, please refer to the actual car.
For 50% of our shipment, the vehicle will be transported by sea, to all main continents such as Africa, South America, Middle East, Oceania and Southeast Asia, either by container or RoRo/Bulk shipment. For inland neighborhood countries of China, such as Russia, Mongolia, Kazakhstan, Myanmar, Vietnam etc. , we can transport vehicles by land.
For light spare parts in urgent need. We can send it by international courier service, such as DHL, TNT, UPS, or Fedex.
On T/T term, 50% down payment is required in advance,and the 50% balance shall be settled before shipment or when products are out of the factory. T/T payment can be negotiated.
Our professional team will provide you with one-stop customs clearance service. We can provide EXW, FOB, FCA payment terms according to customers’ need.
