| Availability: | |
|---|---|
| Quantity: | |
Basic configuration | |
Engine | Cummins B210 33 |
| Drive type | 6*6 |
Gearbox | Manual Eight-speed gearbox |
Transfer box | Mechanical high and low gears |
Vehicle Frame | 860*232mm, Double layer |
| Driver Cab | Dongfeng Cab |
Axle | 5T/5T/5T |
Tire | 12.5R20(6+1) |
Vehicle Suspension | Steel Plate Spring 10/12pcs |
Detailed parameter | |
Overall Vehicle Dimension | 7855*2490*3080mm |
| Cargobox Dimension | 4800*2300*800mm |
| Wheelbase | 3475+1250mm |
Wheel Track | 2020mm |
GVW | 15000kg |
| Curb Weight | 9100kg |
| Engine Displacement | 5900ml |
| Maximum power | 155kw |
| Maximum speed | ≥85km/h |
| Engine Torque | 700N.m |
Approach Angle/departure Angle | 26°/20° |
Oil Tank volume | 220L |
Minimum ground clearance | 315mm |
| Obstacle Crossing height | 510mm |
Note: This configuration is for reference only, please refer to the actual car.

















For 50% of our shipment, the vehicle will be transported by sea, to all main continents such as Africa, South America, Middle East, Oceania and Southeast Asia, either by container or RoRo/Bulk shipment. For inland neighborhood countries of China, such as Russia, Mongolia, Kazakhstan, Myanmar, Vietnam etc. , we can transport vehicles by land.
For light spare parts in urgent need. We can send it by international courier service, such as DHL, TNT, UPS, or Fedex.

On T/T term, 50% down payment is required in advance,and the 50% balance shall be settled before shipment or when products are out of the factory. T/T payment can be negotiated.

Our professional team will provide you with one-stop customs clearance service. We can provide EXW, FOB, FCA payment terms according to customers’ need.
